Digital Dental Laboratory Dental Implant System 5.0mm-7.0mm Wide Diameter

Digital Dental Laboratory Dental Implant System 5.0mm-7.0mm Wide Diameter

5.0mm china dental laboratory

5.0mm digital dental laboratory

7.0mm china dental laboratory

Place of Origin:

China

Chat Now
Request A Quote
Product Details
SuSbstrate Material:
Titanium Alloy (Ti-6Al-4V ELI)
Regular Diameter (RD):
Typically 3.75 – 4.5 Mm
Wide Diameter (WD:
Typically 5.0 – 7.0 Mm
Body Shape:
Tapered / Cylindrica/Hybrid
Implant-Abutment Connection Type:
Internal Hex/Octagon
Retention Mechanism For Prosthesis:
Cement-Retained
Highlight:

5.0mm china dental laboratory

,

5.0mm digital dental laboratory

,

7.0mm china dental laboratory

Payment & Shipping Terms
Minimum Order Quantity
Negotiable
Packaging Details
Standard Packaging
Delivery Time
7-15 Working Days
Payment Terms
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Product Description
Digital Dental Laboratory Implant System

Advanced dental implant system featuring commercially pure titanium tapered body shape with internal connection, designed specifically for prosthodontics applications.

Dental Implant Overview

Dental implants serve as artificial tooth roots manufactured from biocompatible materials. Surgically placed in the jawbone, they provide a stable foundation for various dental prostheses. For prosthodontists, implants represent essential solutions for tooth replacement, supporting everything from single crowns to complete-arch fixed bridges and removable overdentures.

Core System Components
  • Implant Fixture (Implant Body): Screw-shaped component inserted into bone that osseointegrates with the jawbone over time
  • Abutment: Connector piece attached to the implant fixture that protrudes through the gum and anchors the final restoration
  • Prosthesis (Superstructure): Custom-made visible tooth replacement (crown, bridge, or denture) fixed onto the abutment

Some systems feature one-piece implants where the fixture and abutment form a single unit, commonly used in specific overdenture applications.

Material Specifications
  • Commercially Pure Titanium (CP Ti) and Titanium Alloys (Ti-6Al-4V): Industry standard offering excellent biocompatibility, strength, and proven osseointegration
  • Zirconia (Ceramic): Metal-free, tooth-colored alternative ideal for aesthetics and patients with metal sensitivities or thin gum tissue
Design and Surface Technology

Modern implant systems differentiate through advanced design features and surface treatments that enhance bone healing and stability:

Macro-design Features
  • Tapered, cylindrical, or hybrid body shapes
  • Varied thread patterns (self-tapping, double-lead threads) for optimal primary stability
Surface Micro-topography
  • Moderately rough surfaces created by advanced techniques including sandblasting with large-grit and acid-etching (SLA), anodization, or calcium-phosphate coating
  • Enhanced surfaces accelerate osseointegration processes
Connection Types
  • Internal Connection (Internal Hex, Morse Taper): Preferred for superior force distribution, microbial seal, and connection stability
  • External Connection (External Hex): Traditional design still in use

Platform Switching: Design feature using an abutment narrower than the implant platform to preserve crestal bone and improve soft tissue aesthetics.

Prosthetic Application Categories
Implants for Fixed Restorations

Designed to accommodate screw-retained or cement-retained crowns and bridges. Includes bone-level implants (placed flush with bone for customized emergence profile) and tissue-level implants (smooth collar above bone for simplified impression taking).

Implants for Removable Overdentures

Specifically engineered to retain removable dentures using specialized attachment systems:

  • Ball/Socket Attachments: Ball abutment on implant snaps into housing in denture
  • Locator® Attachments: Low-profile system with interchangeable retention inserts for customizable retention
  • Bar Attachments: Custom metal bar connects multiple implants, with denture clipping onto bar for exceptional stability
Full-Arch Fixed Solutions

Products supporting protocols like All-on-4® concept, featuring tilted implants, angled multi-unit abutments, and immediate-loading designs. Enables full set of fixed teeth supported by four implants, often with provisional prosthesis delivered same-day.

Complete Denture Restoration Applications

For edentulous patients, implant systems revolutionize traditional dentures. Implant-supported overdentures utilize 2-4 implants to provide enhanced retention and stability, significantly improving chewing function and comfort compared to conventional dentures. Attachment system selection (Locator, ball, or bar) depends on patient anatomy, manual dexterity, and clinical requirements.

Dental implant systems represent highly engineered medical devices engineered to ensure predictable, long-term bone integration. They provide versatile and reliable anchorage for comprehensive prosthodontic treatments, from single-tooth replacement to complex full-mouth rehabilitations.
