CPTi Ti-6Al-4V Body Dental Lab Zirconia Implant System For Prosthodontics

CPTi Ti-6Al-4V Body Dental Lab Zirconia Implant System For Prosthodontics

cpti dental lab zirconia

cpti zirconia implant system

ti-6al-4v dental lab zirconia

Place of Origin:

China

Chat Now
Request A Quote
Product Details
SuSbstrate Material:
Commercially Pure Titanium (CPTi, Grades 1-4)/ Titanium Alloy (Ti-6Al-4V ELI)
Regular Diameter (RD):
Typically 3.75 – 4.5 Mm
Wide Diameter (WD:
Typically 5.0 – 7.0 Mm
Body Shape:
Tapered / Cylindrica/Hybrid
Implant-Abutment Connection Type:
Internal Connection/ Internal Hex/Octagon
Retention Mechanism For Prosthesis:
Screw-Retained/Cement-Retained
Highlight:

cpti dental lab zirconia

,

cpti zirconia implant system

,

ti-6al-4v dental lab zirconia

Payment & Shipping Terms
Minimum Order Quantity
Negotiable
Packaging Details
Standard Packaging
Delivery Time
7-15 Working Days
Payment Terms
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Product Description
Dental Lab Zirconia Price Implant System with Commercially Pure Titanium Tapered Body Shape and Internal Connection for Prosthodontics
China Implant Dental Lab - Dental Implant Products in Prosthodontics

Functioning as an artificial tooth root, a dental implant is produced from biocompatible materials and surgically embedded in the jawbone to carry a dental prosthesis. In prosthodontics, implants are a cornerstone for the replacement of missing teeth, ranging from single crowns and full-arch fixed bridges to removable overdentures.

Core Components of an Implant System

An implant product is not a single piece but a system, generally composed of three main parts:

  • Implant Fixture (Implant Body): The screw-shaped component inserted into the bone. It osseointegrates (fuses) with the jawbone over time.
  • Abutment: A connector piece attached to the implant fixture. It protrudes through the gum and serves as the anchor for the final restoration.
  • Prosthesis (Superstructure): The visible, custom-made tooth replacement - a crown, bridge, or denture - which is fixed onto the abutment.

Some systems also offer one-piece implants where the fixture and abutment are a single unit, often used in specific overdenture cases.

Common Materials
Commercially Pure Titanium (CP Ti) and Titanium Alloys (Ti-6Al-4V)

The gold standard due to excellent biocompatibility, strength, and proven osseointegration.

Zirconia (Ceramic)

A metal-free, tooth-colored alternative prized for aesthetics and in patients with metal sensitivities or thin gum tissue. Zirconia implants are a growing segment of the product range.

Design and Surface Technology

Modern implant products are differentiated by their design features and surface treatments that enhance bone healing and stability:

Macro-design

Tapered, cylindrical, or hybrid body shapes. Thread patterns vary (e.g., self-tapping, double-lead threads) to achieve high primary stability.

Surface Micro-topography

Most systems use moderately rough surfaces created by techniques like sandblasting with large-grit and acid-etching (SLA), anodization, or calcium-phosphate coating. These surfaces accelerate osseointegration.

Connection Type
  • Internal Connection (e.g., Internal Hex, Morse Taper): Widely preferred for better force distribution, microbial seal, and connection stability.
  • External Connection (e.g., External Hex): The traditional design, still in use.

Platform Switching: An abutment narrower than the implant platform, designed to preserve crestal bone and improve soft tissue aesthetics.

Product Categories by Prosthetic Indication

From the prosthodontist's perspective, implant products are selected based on the type of prosthesis planned:

Implants for Fixed Restorations

These must accommodate screw-retained or cement-retained crowns and bridges. Products include bone-level (placed flush with bone, allowing customized emergence profile) and tissue-level implants (a smooth collar sits above the bone, simplifying impression taking).

Implants for Removable Overdentures

Designed to retain removable dentures. Key products include narrow-diameter/mini-implants and standard implants with special overdenture attachments.

Full-Arch Fixed Solutions

Products for protocols like All-on-4® Concept often include tilted implants, angled multi-unit abutments, and immediate-loading designs, allowing a full set of fixed teeth to be supported by only four implants.

Overdenture Attachment Systems
  • Ball/Socket Attachments: A ball abutment on the implant snaps into a housing in the denture.
  • Locator® Attachments: A popular, low-profile system with interchangeable retention inserts for varying retention needs.
  • Bar Attachments: A customized metal bar connects multiple implants, and the denture clips onto the bar for excellent stability.
Role of Implant Products in Complete Denture Restoration

For edentulous patients, implant products transform traditional dentures. An implant-supported overdenture uses 2-4 implants to provide retention and stability, dramatically improving chewing function and comfort compared to conventional dentures. The choice of attachment system (Locator, ball, or bar) depends on the patient's anatomy, manual dexterity, and budget.

In conclusion, prosthodontic dental implants are advanced, carefully engineered systems built to achieve predictable, sustainable osseointegration. They constitute a versatile and reliable foundation for the entire continuum of tooth replacement, from a single-unit restoration to complex full-arch and full-mouth cases.
